Tebco Crosstrail 27.5 E-MTB

Tebco Crosstrail 27.5 E-MTB

TEBCO

Regular price $2,599.00 Sale

CLICK 'N' COLLECT
Collection in 1-7 days. More info »

The TEBCO Crosstrail is a cross country bike. This bike has all the rail trails and tracks covered.

FEATURES

  • 650B WHEELS / ALLOY FRAME
  • WEIGHT– 25KG INCLUDING BATTERY
  • MAX. SPEED 25KMH / MAX. RANGE 100KM
  • 250W MOTOR / 9 LEVEL PEDAL ACTIVATION
  • 36V 14AH SAMSUNG LITHIUM BATTERY
  • LATEST IN-FRAME BATTERY DESIGN
  • HIGH QUALITY 2.2IN KENDA K1027 TYRES
  • 7 SPEED SHIMANO TRIGGER SHIFTERS
  • LCD SPEEDO BATTERY INDICATOR TRIP COMPUTER
  • TEKTRO ARIES DISC BRAKES FRONT AND REAR



SPECIFICATIONS

MECHANICAL

Frame 6061 Grade Alloy
Wheel Size 650B 36H Front and Rear
Fork Suntour XCT-ATB DS 27.5"
Handlebar PROMAX HB3188SP x 31.8
Stem PROMAX MA-400
Seatpost PROMAX SP-252 & 31.6 x 350mm
Seat Clamp PROMAX 335QX
Saddle SR sport saddle
Shifters SHIMANO ASLM3157RC-7
Derailleur SHIMANO ARDTY500D
Rims PARWEIER P23D 27.5
Hubs MODUS Aluminium
Spokes 13g Stainless Steel
Tyres KENDA K1027 27.5 x 2.2in Tyres
Cranks PROMAX R42P/32 170MM 42T
Pedals WELLGO
Chain KMC Z5GY
Brakes Front TEKTRO Aries Mechanical Disc
Brakes Rear TEKTRO Aries Mechanical Disc
Brake Levers WUXING 240PPD/4 Locking With Power Cut Off
Stand Chain Stay Side Mount Adjustable Alloy

ELECTRICAL

Motor

EIWOL 250W 36V 05RX 36V

Controller

15Ah LISHUI Brushless LSW1155-59M

Battery

SAMSUNG 36V 14Ah 40pcs 18650 3500MAh

Battery Life

Up to 800 recharges from flat

Battery Weight

2.5kg

Display Panel

KEY DISPLAY KD21C-U

Operation Controls

Left Handlebar KD21C Compatible

Pedal Activation

KTV12

Charger

SANS 36V 2A Australian standard

Main Cable

JULET 1T3 Waterproof Quick Release

Audible Warning

HONKA HOOTA Black

Max Speed

25kmh

Max Range

100kmh 1:1 Pedal Assist

Bicycle Weight

25kg incl battery

SIZING

Length 1800mm
Width 690mm
Max Seat Height 1100mm
Min Seat Height 840mm
Step Over 450mm
