SPECIFICATIONS
Frame | All-New, Smartform C2 Alloy, SAVE dropped seatstays, tapered headtube, post mount disc, StraightShot internal cable routing, dropper post compatible BSA 73, 12mm thru axle, Boost 148 |
Fork | RockShox Judy Silver TK, 120mm, Solo Air, 15x110 thru-axle, 51mm offset |
Rear Shock | N/A |
Crank | FSA Alpha Drive, 30T |
Bottom Bracket | Cartridge, square taper |
Cassette | Shimano Deore M5100, 11-51, 11-speed |
Chain | KMC X11, 11-speed |
Front Derailleur | N/A |
Rear Derailleur | Shimano Deore M5100 |
Shifters | Shimano Deore M5100, 11-speed |
Brakes | Shimano MT200 hydraulic disc, 180/160mm RT10 rotors |
Brake Levers | Shimano MT200 hydraulic disc |
Grips | Cannondale Locking Grips |
Handlebar | FSA Alloy Riser, 15mm rise, 760mm |
Stem | Cannondale, 6061 Alloy, 31.8, 7° |
Headset | Integrated Sealed Bearing, Tapered |
Seatpost | TranzX Dropper, 31.6, Internal Routing, 130mm |
Saddle | Cannondale Trail, 170mm, steel rails |
Hubs | (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT400 12x148mm thru-axle |
Rims | WTB STX i25 TCS, 32h, tubeless ready |
Spokes | Stainless Steel, 14g |
Tyres | (F) WTB Breakout, 29 x 2.3" / (R) WTB Trail Boss, 29 x 2.25" |
All prices and specifications are subject to change without notice. |
