SPECIFICATIONS
Sizes | S, M, L, XL, XXL |
Colour | Satin Black / Cyan, Silver / Orange |
Frame | ADT 6061 Formtech Alloy, Replaceable Hanger, internal brake cable |
Fork | SR Suntour XCT30, 100mm Travel, Lock-out. |
Front Derailleur | Shimano Altus |
Rear Derailleur | Shimano Altus 9sp Shadow |
Shifters | Shimano Altus 18sp |
Crankset | Shimano MT101 36/22T |
Brakes | Shimano MT200 Hydraulic Disc, 160mm Rotors |
Brake Levers | Shimano MT200 Hydraulic |
Wheelset / Rims | Weinmann XRD28 Double-wall Alloy 32H |
Hubs | Shimano TX505 Alloy Centrelock Cassette 32H |
Spokes | Stainless Steel |
Cassette | Shimano HG200 Cassette, 11-36T, 9sp |
Handlebar | Alloy 31.8 with 9deg back sweep and 12mm riser, S=660mm, M-XXL=680mm |
Handlebar Stem | Zero 31.8mm Alloy Ahead, 6 deg |
Headset | Semi-Integrated Aheadset 1-1/8" |
Grips | Zero Strike Dual Compound |
Pedals | Nylon platform with ball bearings |
Tyres | Victory 27.5x2.20 or 29x2.2" MTB tyre with AV tube |
Saddle | Zero Zealth Sport |
Seat Post | Zero Alloy 30.9mm, S-L=350mm, XL/XX=400mm |
Bottom Bracket | Cartridge |
Chain | KMC Z-9 |
